40A 60A 80A 100A MPPT Solar Charge Controller 12V/24V/36V/48V Auto Battery Regulator LCD Display,for AGM, Gel, Flooded and Lithium Battery Charging

Advanced MPPT Technology - Delivers up to 99% tracking efficiency,automatically optimizing power harvest under varying conditions.

40A with maximum 520W (12V)/1040W (24V) solar input, Supports maximum 75V solar panel voltage input (Voc),

60A with maximum 780W(12V)/1560W(24V)/2340W(36V)/3120W(48V)  solar input, Supports maximum 150V solar panel voltage input (Voc)

80A with maximum 1040W(12V)/2080W(24V)/3102W(36V)/4160W(48V) solar input, Supports maximum 150V solar panel voltage input (Voc)

100A with maximum 1300W(12V)/2600W(24V)/3900W(36V)/5200W(48V) solar input, Supports maximum 150V solar panel voltage input (Voc)

User-Friendly Operation - Clear LCD display shows real-time data, with simple button navigation for voltage/battery type settings

Multi-Battery Support - Compatible with gel, sealed, flooded lead-acid, and lithium batteries (LiFePO4/Li(NiCoMn)O2), Support preset battery charging parameters

Comprehensive Protection - Built-in safeguards against over-voltage, over-discharge, reverse polarity, overload, and overheating with IP30 protection for harsh environments (-20℃ to +55℃).

Smart Load Control - Offers 4 working modes (manual/light control/light +time control/reverse control) with 20A discharge capacity, ideal for diverse off-grid applications.

Description:

Y&H ME Series MPPT Solar Charge Controller uses MPPT maximum power point tracking technology with up to 99% efficiency, making better use of solar energy than traditional PWM SCCs. It supports automatic recognition of 12V/24V systems(40A)/ 12V/24V/36V/48V systems(60A/80A/100A) and is compatible with multiple battery types, making it an ideal choice for home photovoltaic systems, RVs, boats, and small off-grid power stations, providing stable and efficient energy management.

Features:

1. High-efficiency MPPT technology: Tracking efficiency up to 99%, 20%-30% more efficient than PWM.

2. Smart compatibility: Supports automatic recognition of 12V/24V systems(40A) / 12V/24V/36V/48V systems(60A/80A/100A), compatible with lithium-ion, lead-acid, and gel batteries.

3. Comprehensive protection: Built-in overcharge, over-discharge, overload, short-circuit, and reverse connection protection to extend battery life.

4. Intelligent Display: LCD screen displays real-time system status, with intuitive operation.

5. Communication Expansion: Supports communication (customizable), enabling remote monitoring.

6. Multi-Scene Applications: Suitable for residential PV systems, RVs, boats, camping, and small off-grid power stations.

7. Durable and Reliable: Industrial-grade design with a wide temperature range, ensuring long-term stable operation.
