Y&H 4.2KW 24VDC On/Off-Grid Solar Hybrid Inverter AC220V Two Load Output Power MPPT 120A Solar Charger Max PV Power 6200W Input



Warranty service:
Our products provide 2-year free warranty and permanent after-sales services.

This is a multi-function inverter/charger, combining functions of inverter, solar charger and battery charger to offer uninterruptible power support with portable size. Its comprehensive LCD display offers user-configurable and easy-accessible button operation such as battery charging current, AC/solar charger priority, and acceptable input voltage based on different applications.

Technical specifications:
120A MPPT Solar Charging Inverter
MAX. PV Array Power: 6200W
Max.PV Open Circuit Voltage: 450Vdc
Starting voltage>90V
MAX.Charging Current:120A
PV Array MPPT Voltage Range: 60~450Vdc
Cold start function(23V)

4200W On Grid/Off-Grid Solar Inverter Features:
*Pure sine wave solar inverter(on/off Grid)
*WIFI&GPRS available for IOS and Android
*Inverter running without battery
*One-key restoration to factory settings
*Built-in lithium battery automatic activation
*Built-in MPPT 120A Solar Charger
*Solar chargeHigh PV input voltage range(90~450VDC)
*Built-in anti-dusk kit for harsh enviroment
*Smart battery charge design to optimize battery life
*Dual output

Dual load output power:
Setting range is from 20.0V to 23.0V for 4.2KW model.Increment of each click is 0.1V. When the battery voltage falls below the setting range, the Main OUT port stops working. Only the Second Out port will work. For areas with frequent power outages and loads that can't be blacked out, you can set the battery voltage to 23 V. Keep more battery capacity for emergencies. If the battery voltage is higher than 23V, the Main OUT port will continue to work.

Restore default settings with one click:
4.2KW All in One MPPT inverter can restore the system settings by one key in case of setting error, avoiding the machine damage caused by setting error. with battery cold start function(23V) ,and automatic restart while AC is recovering to well protect your system.

Various uses:
On/ Off-grid working mode, you can use inverter as energy storage device without power Grid (Off Grid). Maybe you will also like to reduce the household electricity bill through it (On Grid).;Can be accessed to a variety of household and office loads, including refrigerators, lamps, televisions, fans, air conditioning and other loads.
