Y&H 300W Grid Tie Micro Inverter DC30-60V AC220V with WIFI Communication Waterproof MPPT Stackable Inverter



Warranty service:
Our products provide 2-year free warranty and permanent after-sales services.


User Manual[Download]

Wi-Fi connection instructions[Download]

The second-generation SG micro-inverter adds mobile phone communication function, Let you monitor the working status of your inverter anytime and anywhere.This Smart On Grid system improves safety; maximizes solar energy harvest; increases system reliability, and simplifies solar system design, installation, maintenance , and management.

Produce green and non-polluting energy. Reduce electricity costs
Single-phase output, Flexible 3-phase PV systems
WIFI With Cloud Monitoring
Multiple units combined into a large solar system
Maximum output power up to 295W; Adapted to 60 & 72 cells PV panels
Maximum 300W input per branch
Integrated AC bus cable, Ready-To-Use
On Grid inverter Low cost, Easy installation and reduced maintenance costs

Technical Specifications:
MPPT Voltage Range:28V-55V
Operation Voltage Range:20V-60V
Maximum Input Voltage:60V
Startup Voltage:20V
Maximum Input Power:300W
Maximum Output Power:300W
Nominal Output Voltage:120VAC / 230VAC
Communication:WIFI With Cloud Monitoring

Regarding the heating problem of the inverter:
this is normal phenomenon. All electronic devices generate heat during operation. The inverter uses aluminum alloy material. Metal can conduct heat better. The inverter also has over-temperature protection if the temperature is high. Then the inverter will automatically reduce the working output efficiency. Or stop working. After cooling down, restart. It is recommended to install the inverter in a ventilated, dry and cool place.
